LED indicators | Activity |
Product colour | Grey |
Form factor | 1U |
Safety | CCC, CE LVD, UL/cUL |
Number of fans | 2 fan(s) |
Electromagnetic compatibility | FCC A, CE A, VCCI, C-Tick, BSMI, CCC |
Rack mounting | Yes |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Power consumption (typical) | 27.49 W |
Security algorithms | 802.1x RADIUS |
Access Control List (ACL) rules | 256 |
IP-MAC-Port binding | Yes |
BPDU filtering/protection | Yes |
Loop protection | Yes |
DHCP features | DHCP client |
Authentication | Guest VLAN, MAC-based authentication, Port-based authentication |
IGMP snooping | Yes |
SSH/SSL support | Yes |
Access Control List (ACL) | Yes |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | -5 - 50 °C |
Operating relative humidity (H-H) | 10 - 90% |
Heat dissipation | 850.58 BTU/h |
Storage relative humidity (H-H) | 5 - 90% |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Switch layer | L2 |
Switch type | Managed |
System event log | Yes |
Traffic classification | Yes |
Height | 44 mm |
Depth | 210 mm |
Width | 440 mm |
Networking standards | IEEE 802.3u |
Auto-negotiation | Yes |
Virtual LAN features | Tagged VLAN |
Full duplex | Yes |
10G support | No |
Auto MDI/MDI-X | Yes |
Flow control support | Yes |
Spanning tree protocol | Yes |
Copper ethernet cabling technology | 1000BASE-T |
Rate limiting | Yes |
Link aggregation | Yes |
IP routing | Yes |
Port mirroring | Yes |
VLAN support | Yes |
Number of VLANs | 4094 |
Noise level | 52.4 dB |
Built-in processor | Yes |
Memory type | DDR3-SDRAM |
Mean time between failures (MTBF) | 294101 h |
Flash Memory | 32 MB |
INTERNAL MEMORY | 128 MB |
PACKAGE WEIGHT | 5.18 kg |
Package depth | 521 mm |
Package width | 365 mm |
Package height | 92 mm |
console port | RJ-45 |
Fiber optic connector | SFP |
Basic switching RJ-45 Ethernet ports quantity | 24 |
SFP module slots quantity | 4 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Harmonized System (HS) code | 85176990 |
Store-and-forward | Yes |
Forwarding rate | 41.7 Mpps |
Jumbo frames | 9216 |
Jumbo Frames support | Yes |
Number of queues | 8 |
Packet buffer memory | 1.5 MB |
Number of static routes | 32 |
Switching capacity | 56 Gbit/s |
MAC Address Table | 16000 entries |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 24 |
Multicast Listener Discovery (MLD) snooping | MLD v1, MLD v2 |
Multicast support | Yes |
Fiber ethernet cabling technology | 1000BASE-X |
