Product colour | Black |
LED indicators | Link |
Rack mounting | Yes |
Electromagnetic compatibility | CE A, VCCI A, FCC A, IC, BSMI |
Power consumption (max) | 51.2 W |
AC input voltage | 100 - 240 V |
Power supply included | Yes |
Security algorithms | SSH |
IGMP snooping | Yes |
DHCP features | DHCP server |
Access Control List (ACL) | Yes |
IP-MAC-Port binding | Yes |
Access Control List (ACL) rules | 768 |
Loop protection | Yes |
Queue scheduling algorithms | Weighted Round Robin (WRR) |
Storage relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -20 - 70 °C |
Operating temperature (T-T) | -5 - 50 °C |
Operating relative humidity (H-H) | 0 - 95% |
Heat dissipation | 174.592 BTU/h |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
Configuring Location Settings (CLI) | Yes |
Switch layer | L3 |
ARP inspection | Yes |
System event log | Yes |
Weight | 3.01 kg |
Width | 440 mm |
Depth | 210 mm |
Height | 44 mm |
Networking standards | IEEE 802.3 |
Number of VLANs | 4094 |
Auto MDI/MDI-X | Yes |
VLAN support | Yes |
10G support | Yes |
Spanning tree protocol | Yes |
Virtual LAN features | Voice VLAN |
Head-of-line (HOL) blocking | Yes |
Link aggregation | Yes |
Flow control support | Yes |
Broadcast storm control | Yes |
Noise level | 50.7 dB |
Memory type | DDR3-SDRAM |
INTERNAL MEMORY | 2048 MB |
Flash Memory | 64 MB |
Mean time between failures (MTBF) | 589984.72 h |
PACKAGE WEIGHT | 4.28 kg |
Package depth | 565 mm |
Package height | 91 mm |
Package width | 351 mm |
Basic switching RJ-45 Ethernet ports quantity | 48 |
SFP+ module slots quantity | 4 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
console port | RJ-45 |
Packet buffer memory | 16 MB |
Jumbo Frames support | Yes |
Switching capacity | 176 Gbit/s |
MAC Address Table | 32000 entries |
Number of static routes | 124 |
Forwarding rate | 130.95 Mpps |
Jumbo frames | 12000 |
Static route | Yes |
Power Over Ethernet (PoE) | No |
Multicast support | Yes |
Fiber ethernet cabling technology | 1000BASE-X |
