Product colour | Black |
Stackable | Yes |
LED indicators | Yes |
International Protection (IP) code | IP40 |
Form factor | DIN rail |
Input current | 1 A |
Power consumption (max) | 7.44 W |
DC input voltage | 12 - 48 V |
Power source | DC |
Storage temperature (T-T) | -20 - 85 °C |
Storage relative humidity (H-H) | 5 - 95% |
Operating relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | -20 - 65 °C |
Switch type | Unmanaged |
Quality of Service (QoS) support | Yes |
Weight | 498 g |
Height | 100 mm |
Width | 190 mm |
Depth | 28 mm |
Networking standards | IEEE 802.3z |
Auto MDI/MDI-X | Yes |
Copper ethernet cabling technology | 1000BASE-T |
Mean time between failures (MTBF) | 392267 h |
Fanless | Yes |
SFP module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Harmonized System (HS) code | 85176990 |
Forwarding rate | 14.88 Mpps |
Store-and-forward | Yes |
MAC Address Table | 4000 entries |
Jumbo frames | 9000 |
Jumbo Frames support | Yes |
Switching capacity | 20 Gbit/s |
Transmission method | Store-and-forward |
Power Over Ethernet (PoE) | No |
