Certification | RoHS, FCC Class B, ICES-003 Class B, CE Class B, C-Tick Class B, VCCI Class B, cUL, CB |
LED indicators | Power |
Product colour | Black |
Housing material | Metal |
Rack mounting | No |
Input current | 1 A |
Input voltage | 5 V |
Power consumption (typical) | 4.5 W |
MAC address filtering | Yes |
Operating temperature (T-T) | 0 - 50 °C |
Storage relative humidity (H-H) | 5 - 90% |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -10 - 70 °C |
Quality of Service (QoS) support | Yes |
Networking standards | IEEE 802.3x |
Auto MDI/MDI-X | Yes |
Full duplex | Yes |
Copper ethernet cabling technology | 10BASE-T |
Flow control support | Yes |
10G support | No |
Mean time between failures (MTBF) | 511323 h |
PACKAGE WEIGHT | 610 g |
Package width | 208 mm |
Package depth | 250 mm |
Package height | 68 mm |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Dimensions (WxDxH) | 162 x 102 x 28 mm |
Data Transfer Rate | 200 Mbit/s |
Harmonized System (HS) code | 85176990 |
Switching capacity | 1.6 Gbit/s |
MAC Address Table | 1000 entries |
Packet buffer memory | 0.768 MB |
Supported data transfer rates | 10/100 Mbps |
Store-and-forward | Yes |
Maximum data transfer rate | 0.1 Gbit/s |
Jumbo Frames support | Yes |
