Product colour | Black |
LED indicators | Activity |
Input current | 1 A |
Power consumption (max) | 8.89 W |
DC input voltage | 12 V |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 5 - 95% |
Heat dissipation | 30.32 BTU/h |
Quality of Service (QoS) support | Yes |
Switch type | Unmanaged |
Width | 280 mm |
Height | 25 mm |
Weight | 770 g |
Depth | 110 mm |
Networking standards | IEEE 802.3x |
Full duplex | Yes |
Auto MDI/MDI-X | Yes |
Copper ethernet cabling technology | 1000BASE-T |
10G support | No |
Cable length detection | Yes |
Flow control support | Yes |
Auto-negotiation | Yes |
Half duplex | Yes |
Mean time between failures (MTBF) | 564658 h |
Fanless | Yes |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Jumbo Frames support | Yes |
Switching capacity | 32 Gbit/s |
Packet buffer memory | 0.512 MB |
Store-and-forward | Yes |
Number of queues | 8 |
Packet forwarding rate (10 Mbps) | 14880 pps |
Jumbo frames | 9216 |
MAC Address Table | 8000 entries |
Packet forwarding rate (100 Mbps) | 148800 pps |
Packet forwarding rate (1 Gbps) | 1488000 pps |
Power Over Ethernet (PoE) | No |
