Certification | FCC Class B, ICES-003 Class B, CE Class B, C-Tick Class B, VCCI Class B, cUL, CB, RoHS |
Product colour | Black |
Rack mounting | No |
Housing material | Metal |
LED indicators | Link |
Input voltage | 5 V |
Power consumption (typical) | 2.8 W |
Input current | 1 A |
MAC address filtering | Yes |
Storage temperature (T-T) | -10 - 70 °C |
Storage relative humidity (H-H) | 5 - 90% |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 50 °C |
Quality of Service (QoS) support | Yes |
Weight | 440 g |
Flow control support | Yes |
10G support | Yes |
Copper ethernet cabling technology | 1000BASE-T |
Full duplex | Yes |
Networking standards | IEEE 802.3az |
Auto MDI/MDI-X | Yes |
Mean time between failures (MTBF) | 2053751 h |
Package depth | 250 mm |
Package width | 208 mm |
Package height | 68 mm |
Included power plug types | EU |
PACKAGE WEIGHT | 654 g |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Connectivity Technology | Wired |
Dimensions (WxDxH) | 162 x 102 x 28 mm |
Data Transfer Rate | 2000 Mbit/s |
Harmonized System (HS) code | 85176990 |
Store-and-forward | Yes |
Jumbo Frames support | Yes |
Switching capacity | 16 Gbit/s |
Maximum data transfer rate | 1 Gbit/s |
Supported data transfer rates | 10/100/1000 Mbps |
MAC Address Table | 8000 entries |
Packet buffer memory | 0.128 MB |
