LED indicators | Yes |
Product colour | Black |
Rack mounting | Yes |
AC input voltage | 100 - 240 V |
Power consumption (max) | 19.5 W |
Queue scheduling algorithms | SPQ |
DHCP features | DHCP client |
IGMP snooping | Yes |
Security algorithms | SSL/TLS |
Heat dissipation | 107.5 BTU/h |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -5 - 50 °C |
Storage relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -40 - 70 °C |
Operating altitude | 0 - 2000 m |
Switch type | Managed |
System event log | Yes |
Switch layer | L2 |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Weight | 2.2 kg |
Depth | 230 mm |
Height | 44 mm |
Width | 280 mm |
Flow control support | Yes |
Broadcast storm control | Yes |
Virtual LAN features | Voice VLAN |
Port mirroring | Yes |
Auto-negotiation | Yes |
10G support | No |
Rate limiting | Yes |
Spanning tree protocol | Yes |
Link aggregation | Yes |
Full duplex | Yes |
Head-of-line (HOL) blocking | Yes |
Number of VLANs | 128 |
Copper ethernet cabling technology | 10BASE-T |
Networking standards | IEEE 802.3u |
Auto MDI/MDI-X | Yes |
VLAN support | Yes |
Fanless | Yes |
Memory type | DRAM |
Flash Memory | 16 MB |
Noise level | 0 dB |
Built-in processor | Yes |
Processor frequency | 125 MHz |
Mean time between failures (MTBF) | 255003 h |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Switching capacity | 48 Gbit/s |
Jumbo Frames support | Yes |
Packet buffer memory | 4.1 MB |
Forwarding rate | 35.71 Mpps |
MAC Address Table | 8000 entries |
Jumbo frames | 9216 |
Store-and-forward | Yes |
Number of queues | 4 |
Power over Ethernet plus (PoE+) ports quantity | 12 |
Total Power over Ethernet (PoE) budget | 100 W |
Power over Ethernet (PoE) power per port | 30 W |
Power Over Ethernet (PoE) | Yes |
Multicast support | Yes |
