Product colour | Black |
LED indicators | Yes |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Power source | AC |
Number of power supply units | 1 |
Power consumption (max) | 9.4 W |
Power supply included | Yes |
IGMP snooping | Yes |
Loop protection | Yes |
Operating temperature (T-T) | -5 - 50 °C |
Storage temperature (T-T) | -40 - 70 °C |
Heat dissipation | 507.23 BTU/h |
Storage relative humidity (H-H) | 0 - 95% |
Operating relative humidity (H-H) | 0 - 95% |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Switch layer | L2 |
Switch type | Managed |
Weight | 1.77 kg |
Height | 44 mm |
Width | 330 mm |
Depth | 180 mm |
Networking standards | IEEE 802.3x |
Number of VLANs | 256 |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
10G support | No |
Full duplex | Yes |
VLAN support | Yes |
Auto MDI/MDI-X | Yes |
Head-of-line (HOL) blocking | Yes |
Flow control support | Yes |
Half duplex | Yes |
Spanning tree protocol | Yes |
Link aggregation | Yes |
Broadcast storm control | Yes |
Port mirroring | Yes |
Mean time between failures (MTBF) | 1274005 h |
Flash Memory | 32 MB |
INTERNAL MEMORY | 128 MB |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Installed SFP modules quantity | 2 |
Jumbo Frames support | Yes |
Packet buffer memory | 4.1 MB |
MAC Address Table | 8000 entries |
Switching capacity | 20 Gbit/s |
Jumbo frames | 10000 |
Number of static routes | 256 |
Forwarding rate | 14.88 Mpps |
Static route | Yes |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 130 W |
Power over Ethernet (PoE) ports quantity | 8 |
Sustainability certificates | CCC |
Sustainability compliance | Yes |
