Rack mounting | Yes |
Number of fans | 2 fan(s) |
Electromagnetic compatibility | FCC A, CE A, VCCI, C-Tick, BSMI, CCC |
Form factor | 1U |
LED indicators | Speed |
Product colour | Black |
Power source | AC/DC |
Power consumption (typical) | 27.49 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
IP-MAC-Port binding | Yes |
IGMP snooping | Yes |
BPDU filtering/protection | Yes |
DHCP features | DHCP client |
Access Control List (ACL) rules | 256 |
Loop protection | Yes |
Access Control List (ACL) | Yes |
Authentication | Guest VLAN, MAC-based authentication, Port-based authentication |
SSH/SSL support | Yes |
Security algorithms | SSH |
Storage relative humidity (H-H) | 5 - 90% |
Heat dissipation | 850.58 BTU/h |
Operating temperature (T-T) | -5 - 50 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Switch layer | L2 |
Traffic classification | Yes |
Switch type | Managed |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Width | 440 mm |
Depth | 210 mm |
Height | 44 mm |
Weight | 3.86 kg |
Rate limiting | Yes |
VLAN support | Yes |
Auto-negotiation | Yes |
Port mirroring | Yes |
Spanning tree protocol | Yes |
Link aggregation | Yes |
Virtual LAN features | Port-based VLAN |
Auto MDI/MDI-X | Yes |
Copper ethernet cabling technology | 10BASE-T |
Full duplex | Yes |
IP routing | Yes |
Number of VLANs | 4094 |
10G support | No |
Flow control support | Yes |
Networking standards | IEEE 802.1w |
Flash Memory | 32 MB |
Memory type | DDR3-SDRAM |
INTERNAL MEMORY | 256 MB |
Noise level | 52.4 dB |
console port | RJ-45 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
SFP module slots quantity | 4 |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Fiber optic connector | SFP |
Harmonized System (HS) code | 85176990 |
Jumbo Frames support | Yes |
Number of static routes | 32 |
MAC Address Table | 16000 entries |
Jumbo frames | 9216 |
Switching capacity | 56 Gbit/s |
Forwarding rate | 41.7 Mpps |
Packet buffer memory | 1.5 MB |
Store-and-forward | Yes |
Number of queues | 8 |
Power over Ethernet (PoE) ports quantity | 24 |
Power Over Ethernet (PoE) | Yes |
Multicast Listener Discovery (MLD) snooping | MLD v1, MLD v2 |
Multicast support | Yes |
Fiber ethernet cabling technology | 1000BASE-X |
