| management functions | |
| Switch-Typ | Managed |
| switch level | L2/L3 |
| Eigenschaft | Nachhaltigkeitskonformität |
| connections and interfaces | |
| Number of basic switching RJ-45 Ethernet ports | 24 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Number of installed SFP modules | 4 |
| console port | RJ-45 |
| network | |
| Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| supported cable types | Cat5, Cat5e |
| Ethernet LAN data transfer rates | 1000 Mbit/s |
| IPv4-Routen | 64 |
| IPv6-Routen | 32 |
| Virtual LAN functions | MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN |
| Number of VLANs | 4094 |
| optical fiber | |
| Ethernet cable cabling technology | 1000BASE-X |
| data transmission | |
| Routing/Switching Capacity | 56 Gbit/s |
| Transferrate | 41,7 Mpps |
| MAC-Adressentabelle | 16000 Eintragungen |
| number of queues | 8 |
| Number of static routes | 96 |
| Number of IP interfaces | 4 |
| Data packet buffer memory | 1,5 MB |
| safety | |
| DHCP functions | DHCP client, DHCP relay, DHCP server, DHCP snooping |
| Access Control List (ACL) Regeln | 256 |
| Zugriffskontrollliste (ACL) Eingang | 256 |
| Supported security algorithms | EAP, SNMP, SNMPv2, SNMPv3 |
| authentication type | AAA, RADIUS, TACACS+ |
| Queue Scheduling Algorithms | Strict Priority Queue (SPQ), Weighted Round Robin (WRR) |
| multicast capabilities | Steuerbarer Multicast |
| Number of filtered multicast groups | 256 |
| Multicast Listener Discovery (MLD) snooping | MLD v1, MLD v2 |
| logs | |
| IPv4 & IPv6 features | Dual stack IPv4/IPv6, ICMPv6, IPv4/IPv6 access-control list (ACL), IPv6 Path MTU Discovery, IPv6 Telnet |
| Design | |
| form factor | 1U |
| LED indicators | Aktivität, Ventilatorausfall, Link, Leistung, Geschwindigkeit |
| number of fans | 2 Lüfter |
| Services | |
| storage type | DDR3-SDRAM |
| storage capacity | 256 MB |
| Flash memory | 32 MB |
| noise level | 52,9 dB |
| Mean Time Between Failures (MTBF) | 331669 h |
| energy | |
| energy source | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| input voltage | 100 - 240 V |
| Power consumption (max.) | 251,5 W |
| energy conservation properties | Überspannungsschutz |
| Power Over Ethernet (PoE) | |
| Number of Power over Ethernet (PoE) ports | 24 |
| Overall Power over Ethernet (PoE) | 193 W |
| operating conditions | |
| operating temperatur | -5 - 50 °C |
| Storage temperature range | -40 - 70 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 0 - 95% |
| heat dissipation | 857,98 BTU/h |
| weight and dimensions | |
| broad | 440 mm |
| depth | 210 mm |
| height | 44 mm |
| Weight | 3,34 kg |
| sustainability | |
| sustainability certificates | UL ECOLOGO |
| certificates | |
| Konformitätsbescheinigungen | BSMI, CB, CCC, CE, Eidgenössische Kommunikationskommission (FCC), Niederspannungsrichtlinie (LVD), VCCI |
