| management functions | |
| Switch-Typ | Managed |
| switch level | L3 |
| Eigenschaft | Power over Ethernet (PoE) |
| connections and interfaces | |
| Number of basic switching RJ-45 Ethernet ports | 48 |
| Quantity of module slots SFP+ | 4 |
| console port | RJ-45 |
| network | |
| Virtual LAN functions | Voice VLAN |
| Number of VLANs | 4094 |
| data transmission | |
| Routing/Switching Capacity | 176 Gbit/s |
| Transferrate | 130,95 Mpps |
| MAC-Adressentabelle | 32000 Eintragungen |
| Number of static routes | 124 |
| Jumbo-Frames | 12000 |
| Data packet buffer memory | 16 MB |
| safety | |
| DHCP functions | DHCP client, DHCP server, DHCP snooping |
| Access Control List (ACL) Regeln | 768 |
| Supported security algorithms | EAP, LEAP, PEAP, SSH, TTLS |
| Queue Scheduling Algorithms | Weighted Round Robin (WRR) |
| multicast capabilities | |
| Design | |
| Product color | Schwarz |
| LED indicators | Aktivität, Link, Leistung, Geschwindigkeit |
| Electromagnetic compatibility | CE A, VCCI A, FCC A, IC, BSMI |
| Services | |
| storage type | DDR3-SDRAM |
| storage capacity | 2048 MB |
| Flash memory | 64 MB |
| noise level | 51,2 dB |
| Mean Time Between Failures (MTBF) | 309053,1 h |
| energy | |
| AC input voltage | 100 - 240 V |
| Power consumption (max.) | 467,3 W |
| Power Over Ethernet (PoE) | |
| Number of Power over Ethernet (PoE) ports | 48 |
| Power over Ethernet (PoE) performance per port | 15,4 W |
| Overall Power over Ethernet (PoE) | 370 W |
| operating conditions | |
| operating temperatur | -5 - 50 °C |
| Storage temperature range | -20 - 70 °C |
| Operating relative humidity | 0 - 95% |
| humidity during storage | 0 - 95% |
| heat dissipation | 1512,676 BTU/h |
| weight and dimensions | |
| broad | 440 mm |
| depth | 430 mm |
| height | 44 mm |
| Weight | 3,85 kg |
| package weight | 5,17 kg |
| Technical details | |
| shipping carton height | 42,8 cm |
| shipping carton width | 47,8 cm |
| shipping carton length | 58,5 cm |
| Net weight of shipping carton | 22,9 kg |
| Quantity per shipping carton | 5 Stück(e) |
| Pallet length (gross) | 110 cm |
| Pallet width (gross) | 120 cm |
| Weight (inner) shipping carton | 27,4 kg |
| certificates | |
| certification | CB, UL, BSMI, CCC |
| logistic data | |
| Goods tariff number (HS) | 85176990 |
