Product colour | Grey |
Number of fans | 1 fan(s) |
LED indicators | Yes |
Stackable | Yes |
Redundant power supply (RPS) support | Yes |
Power source | DC |
AC input frequency | 50 - 60 Hz |
Power consumption (max) | 30.36 W |
AC input voltage | 100 - 240 V |
Queue scheduling algorithms | Weighted Round Robin (WRR) |
Access Control List (ACL) | Yes |
IGMP snooping | Yes |
SSH/SSL support | Yes |
Access Control List (ACL) egress | 512 |
DHCP features | DHCP client |
BPDU filtering/protection | Yes |
Loop protection | Yes |
Authentication | Guest VLAN, MAC-based authentication, Port-based authentication |
Access Control List (ACL) ingress | 2048 |
Operating temperature (T-T) | 0 - 50 °C |
Storage temperature (T-T) | -40 - 70 °C |
Heat dissipation | 103.59 BTU/h |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Switch layer | L3 |
ARP inspection | Yes |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
Depth | 250 mm |
Weight | 3.2 kg |
Height | 44 mm |
Width | 440 mm |
Networking standards | IEEE 802.3az |
Flow control support | Yes |
Number of VLANs | 4000 |
Copper ethernet cabling technology | 1000BASE-T |
Head-of-line (HOL) blocking | Yes |
Virtual LAN features | Private VLAN |
Link aggregation | Yes |
Spanning tree protocol | Yes |
VLAN support | Yes |
10G support | Yes |
Port mirroring | Yes |
Virtual stacking (units) | 32 |
Noise level | 47 dB |
Physical stacking (units) | 9 |
Mean time between failures (MTBF) | 388361 h |
Routing protocols | RIP |
USB 2.0 ports quantity | 1 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
SFP+ module slots quantity | 4 |
Power connector | AC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 24 |
10G Ethernet (copper) ports quantity | 2 |
Fiber optic connector | SFP+ |
Packet buffer memory | 2 MB |
Forwarding rate | 125 Mpps |
Switching capacity | 168 Gbit/s |
Jumbo frames | 9000 |
Jumbo Frames support | Yes |
MAC Address Table | 16384 entries |
Power Over Ethernet (PoE) | No |
Multicast support | Yes |
