| management functions | |
| Switch-Typ | Managed |
| switch level | L2 |
| Eigenschaft | Upgradefähige Firmware |
| MIB support | RFC 1757 RMON 1,2,3,9; RFC 2674 Q MIB RFC‑1213 MIB‑II; RFC‑1493 MIB; RFC 2233 IF MIB |
| connections and interfaces | |
| Number of basic switching RJ-45 Ethernet ports | 8 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Quantity of SFP module slots | 4 |
| Optical cable connector | LC |
| network | |
| mesh standard | IEEE 802.1D, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3x |
| Virtual LAN functions | Tagged VLAN, Protocol-based VLAN, Port-based VLAN |
| Number of VLANs | 1024 |
| data transmission | |
| MAC-Adressentabelle | 8000 Eintragungen |
| Jumbo-Frames | 9000 |
| safety | |
| DHCP functions | DHCP server, DHCP snooping, DHCP relay, DHCP client |
| Supported security algorithms | HTTPS, SNMP, SNMPv3, SSH |
| authentication type | IEEE 802.1x, RADIUS |
| Queue Scheduling Algorithms | Weighted Round Robin (WRR) |
| multicast capabilities | |
| Design | |
| Product color | Schwarz |
| LED indicators | LAN, Status |
| International degree of protection (IP code) | IP30 |
| Electromagnetic compatibility | FCC 15, EN 61000‑6‑2, EN 61000‑6‑4, EN 61000‑4‑2, ‑3, ‑4, ‑5, ‑6 |
| Services | |
| energy | |
| DC input voltage | 12 - 58 V |
| Power consumption (max.) | 17 W |
| energy conservation properties | Überstrom, Umgekehrte Polarität |
| operating conditions | |
| operating temperatur | -40 - 75 °C |
| Storage temperature range | -40 - 85 °C |
| Operating relative humidity | 5 - 95% |
| weight and dimensions | |
| broad | 61 mm |
| depth | 154 mm |
| height | 109 mm |
| Weight | 1,09 kg |
| package weight | 1,53 kg |
| Technical details | |
| shipping carton height | 27 cm |
| shipping carton width | 41 cm |
| shipping carton length | 60 cm |
| Net weight of shipping carton | 15,3 kg |
| Quantity per shipping carton | 10 Stück(e) |
| Pallet length (gross) | 120 cm |
| Pallet width (gross) | 110 cm |
| Weight (inner) shipping carton | 16,5 kg |
| certificates | |
| certification | IEC60068‑2‑6, IEC60068‑2‑27, IEC60068‑2‑32, UL 60950‑1, CE, FCC, RoHS, WEEE |
| logistic data | |
| Goods tariff number (HS) | 85176990 |
