management functions | |
Switch-Typ | Unmanaged |
switch level | L2 |
Eigenschaft | Nachhaltigkeitskonformität |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 5 |
Basic Switching RJ-45 Ethernet Ports-Typ | 2.5G Ethernet (100/1000/2500) |
Number of 2.5G Ethernet (copper) ports | 5 |
network | |
mesh standard | IEEE 802.1p, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
data transmission | |
Routing/Switching Capacity | 25 Gbit/s |
Transferrate | 18,6 Mpps |
MAC-Adressentabelle | 4000 Eintragungen |
Data packet buffer memory | 8,1 MB |
safety | |
multicast capabilities | |
Design | |
Product color | Schwarz |
LED indicators | Aktivität, Link, Leistung |
Services | |
Mean Time Between Failures (MTBF) | 765190 h |
energy | |
energy source | Gleichstrom |
DC input voltage | 12 V |
input current | 1 A |
Power consumption (standard operation) | 4,918 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -10 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
heat dissipation | 16,78 BTU/h |
weight and dimensions | |
broad | 100,5 mm |
depth | 82 mm |
height | 28 mm |
Weight | 238,6 g |
sustainability | |
certificates | |
Konformitätsbescheinigungen | BSMI, CE, Niederspannungsrichtlinie (LVD), RoHS |
