DIN rail mounting | Yes |
LED indicators | Yes |
International Protection (IP) code | IP30 |
Wall mountable | Yes |
Product colour | Black |
Housing material | Metal |
Rack mounting | Yes |
Electromagnetic compatibility | CISPR 22, FCC Part 15B Class A |
Number of fans | 0 fan(s) |
DC input voltage | 46 - 54 V |
Power consumption (max) | 260 W |
Authentication type | RADIUS |
Queue scheduling algorithms | SPQ |
Authentication | Port-based authentication |
DHCP features | DHCP client |
Security algorithms | 802.1x RADIUS |
IGMP snooping | Yes |
Heat dissipation | 887.16 BTU/h |
Storage temperature (T-T) | -40 - 85 °C |
Operating temperature (T-T) | -40 - 65 °C |
Storage relative humidity (H-H) | 0 - 95% |
Operating relative humidity (H-H) | 0 - 95% |
System event log | Yes |
Configuring Location Settings (CLI) | Yes |
Switch type | Managed |
Quality of Service (QoS) support | Yes |
Switch layer | L2 |
Web-based management | Yes |
Weight | 1.76 kg |
Width | 171.2 mm |
Depth | 53 mm |
Height | 210 mm |
Virtual LAN features | Port-based VLAN |
Active link detection | Yes |
Spanning tree protocol | Yes |
Link aggregation | Yes |
10G support | No |
Number of VLANs | 4094 |
Flow control support | Yes |
VLAN support | Yes |
Copper ethernet cabling technology | 100BASE-TX |
Broadcast storm control | Yes |
Networking standards | IEEE 802.1D |
Full duplex | Yes |
Auto-negotiation | Yes |
Auto MDI/MDI-X | Yes |
Port mirroring | Yes |
Mean time between failures (MTBF) | 205689 h |
Management protocols | SNMP v1/v2c/v3, SNTP, Telnet |
Gigabit Ethernet (copper) ports quantity | 10 |
Basic switching RJ-45 Ethernet ports quantity | 10 |
SFP module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
console port | RJ-45 |
Harmonized System (HS) code | 85176990 |
Forwarding rate | 17.85 Mpps |
Jumbo frames | 9216 |
Store-and-forward | Yes |
Switching capacity | 24 Gbit/s |
Jumbo Frames support | Yes |
MAC Address Table | 8000 entries |
Total Power over Ethernet (PoE) budget | 240 W |
Power over Ethernet (PoE) ports quantity | 8 |
Power over Ethernet (PoE) power per port | 30 W |
Power Over Ethernet (PoE) | Yes |
Multicast support | Yes |
Warnings | Do not open the case or try to repair it yourself. |
Fiber ethernet cabling technology | 1000BASE-X |
