Form factor | 1U |
Rack mounting | Yes |
Product colour | Blue |
Housing material | Metal |
AC input voltage | 100 - 240 V |
Input current | 6.5 A |
Power source | AC |
Power consumption (max) | 400 W |
DHCP features | DHCP client |
Loop protection | Yes |
Operating relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -40 - 85 °C |
Operating temperature (T-T) | 0 - 45 °C |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
System event log | Yes |
Depth | 221 mm |
Width | 440 mm |
Height | 44 mm |
Weight | 2.83 kg |
Networking standards | IEEE 802.3z |
VLAN support | Yes |
Full duplex | Yes |
Number of VLANs | 4094 |
10G support | No |
Auto MDI/MDI-X | Yes |
Link aggregation | Yes |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Combo SFP ports quantity | 2 |
MAC Address Table | 16000 entries |
Switching capacity | 14.8 Gbit/s |
Packet buffer memory | 4 MB |
Forwarding rate | 11.01 Mpps |
Store-and-forward | Yes |
Power over Ethernet (PoE) power per port | 30 W |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 370 W |
Power over Ethernet (PoE) ports quantity | 24 |
Warnings | The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations. |
