DIN rail mounting | No |
Stackable | Yes |
Reset button | Yes |
LED indicators | PoE |
Product colour | Black |
Number of fans | 1 fan(s) |
Form factor | 1U |
Redundant fans support | No |
Rack mounting | Yes |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Power supply included | Yes |
Redundant power supply (RPS) support | No |
Power source | AC |
MAC address entries | Dynamic MAC address entries |
Loop protection | Yes |
SSH/SSL support | Yes |
DHCP features | DHCP snooping |
Access Control List (ACL) | Yes |
IGMP snooping | Yes |
Configuring Location Settings (CLI) | Yes |
Web-based management | Yes |
Switch layer | L2/L4 |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
Height | 44 mm |
Depth | 180 mm |
Width | 285 mm |
Auto-sensing | Yes |
IP routing | Yes |
Auto-negotiation | Yes |
Spanning tree protocol | Yes |
Networking standards | IEEE 802.3u |
10G support | No |
Number of VLANs | 4096 |
Full duplex | Yes |
VLAN support | Yes |
Package height | 49 mm |
Package width | 290 mm |
Package Type | Box |
Package depth | 185 mm |
User guide | Yes |
CABLES INCLUDED | DC |
console port | RJ-45 |
Gigabit Ethernet (copper) ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
SFP module slots quantity | 2 |
Minimum order quantity | 1 pc(s) |
Forwarding rate | 14.88 Mpps |
Store-and-forward | Yes |
Jumbo Frames support | Yes |
Switching capacity | 20 Gbit/s |
MAC Address Table | 8000 entries |
Power over Ethernet (PoE) pass through | No |
Power over Ethernet plus (PoE+) ports quantity | 8 |
Power over Ethernet (PoE) type supported | Active PoE |
Power over Ethernet (PoE) power per port | 30 W |
Total Power over Ethernet (PoE) budget | 150 W |
Power over Ethernet (PoE) voltage | 48 V |
Power over Ethernet (PoE) ports quantity | 8 |
Power Over Ethernet (PoE) | Yes |
Multicast support | Yes |
