Certification | FCC Class B, CE, RoHS |
Housing material | Metal |
Product colour | Black |
LED indicators | Activity |
Power consumption (max) | 75 W |
AC input frequency | 50 - 60 Hz |
Input current | 2.5 A |
Power supply included | Yes |
AC input voltage | 100 - 240 V |
Storage temperature (T-T) | 0 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Height | 28 mm |
Width | 140 mm |
Depth | 78 mm |
Weight | 600 g |
Networking standards | IEEE 802.3at |
Copper ethernet cabling technology | 1000BASE-T |
Cable types supported | Cat6 |
Auto MDI/MDI-X | Yes |
10G support | No |
Flow control support | Yes |
CABLES INCLUDED | AC |
Manual | Yes |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Harmonized System (HS) code | 85176990 |
Store-and-forward | Yes |
Switching capacity | 10 Gbit/s |
MAC Address Table | 2048 entries |
Packet forwarding rate (1 Gbps) | 1488000 pps |
Packet forwarding rate (100 Mbps) | 148800 pps |
Packet forwarding rate (10 Mbps) | 14880 pps |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 26 W |
