Certification | FCC, CE, RCM, IC, UKCA |
LED indicators | Link |
Housing material | Metal |
Product colour | Black |
Power consumption (max) | 2 W |
Input current | 1.22 A |
Power supply included | Yes |
Power source | DC |
DC input voltage | 48 V |
MAC address filtering | Yes |
IGMP snooping | Yes |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -20 - 60 °C |
Storage relative humidity (H-H) | 10 - 90% |
Switch type | Unmanaged |
Quality of Service (QoS) support | Yes |
Height | 27 mm |
Depth | 145 mm |
Weight | 260 g |
Width | 80 mm |
Networking standards | IEEE 802.3x |
Auto MDI/MDI-X | Yes |
Auto-negotiation | Yes |
MAC address auto-learning supported | Yes |
Flow control support | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
MAC address auto-aging supported | Yes |
Package height | 51 mm |
Package width | 190 mm |
PACKAGE WEIGHT | 750 g |
Package depth | 230 mm |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Jumbo frames | 9000 |
MAC Address Table | 2 entries |
Switching capacity | 10 Gbit/s |
Jumbo Frames support | Yes |
Power over Ethernet (PoE) power per port | 30 W |
Total Power over Ethernet (PoE) budget | 60 W |
Power Over Ethernet (PoE) | Yes |
Multicast support | Yes |
