Housing material | Metal |
Product colour | Blue |
LED indicators | Yes |
DC input voltage | 48 V |
Power consumption (max) | 120 W |
Power consumption (typical) | 10 W |
Input current | 2.5 A |
Storage relative humidity (H-H) | 5 - 95% |
Operating relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -40 - 85 °C |
Operating temperature (T-T) | -10 - 55 °C |
Switch type | Unmanaged |
Depth | 103.3 mm |
Height | 27.8 mm |
Width | 217.6 mm |
Weight | 550 g |
10G support | No |
Full duplex | Yes |
Auto MDI/MDI-X | Yes |
Networking standards | IEEE 802.3bt |
PACKAGE WEIGHT | 1.22 kg |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Gigabit Ethernet (copper) ports quantity | 2 |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Switching capacity | 5.6 Gbit/s |
Forwarding rate | 4.166 Mpps |
MAC Address Table | 16000 entries |
Store-and-forward | Yes |
Total Power over Ethernet (PoE) budget | 110 W |
Power over Ethernet (PoE) ports quantity | 8 |
Power over Ethernet (PoE) power per port | 60 W |
Power Over Ethernet (PoE) | Yes |
