Housing material | Metal |
Power consumption (max) | 50 W |
Input current | 1.0 A |
DC input voltage | 48 V |
Storage temperature (T-T) | -40 - 85 °C |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 5 - 95% |
Operating relative humidity (H-H) | 5 - 95% |
Width | 121.1 mm |
Height | 27.6 mm |
Depth | 83.1 mm |
Weight | 190 g |
Auto MDI/MDI-X | Yes |
Sustainability certificates | REACH |
Basic switching RJ-45 Ethernet ports quantity | 2 |
PoE Port | 4*10/100Mbps |
MAC Address Table | 2000 entries |
Store-and-forward | Yes |
Forwarding rate | 0.89 Mpps |
Switching capacity | 1.2 Gbit/s |
Total Power over Ethernet (PoE) budget | 45 W |
Power Over Ethernet (PoE) | Yes |
Warnings | Ensure the unit is adequately ventilated during operation. |
Mounting options | Tabletop |
