Form factor | 1U |
Rack mounting | Yes |
Stackable | Yes |
Airflow direction | Side-to-side airflow |
Power source | AC |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Power supply included | Yes |
Power consumption (max) | 29.3 W |
Access Control List (ACL) | Yes |
SSH/SSL support | Yes |
Authentication type | RADIUS, TACACS+ |
Authentication | MAC-based authentication, Web-based authentication |
Heat dissipation | 100 BTU/h |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 15 - 95% |
Storage relative humidity (H-H) | 15 - 95% |
Operating temperature (T-T) | 0 - 45 °C |
Switch layer | L3 |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
Web-based management | Yes |
Width | 442.5 mm |
Height | 43.9 mm |
Depth | 200.2 mm |
Weight | 2.41 kg |
10G support | Yes |
VLAN support | Yes |
Rate limiting | Yes |
Networking standards | IEEE 802.1Q |
Full duplex | Yes |
Auto MDI/MDI-X | Yes |
Virtual LAN features | Private VLAN |
Spanning tree protocol | Yes |
Link aggregation | Yes |
Auto-sensing | Yes |
Half duplex | Yes |
Built-in processor | Yes |
Processor model | ARM Cortex-A9 |
Virtual stacking (units) | 8 |
Flash Memory | 4096 MB |
INTERNAL MEMORY | 1024 MB |
Processor frequency | 1016 MHz |
Memory type | DDR3-SDRAM |
IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL) |
Routing protocols | VRRP |
Management protocols | SNMPv1, SNMPv2, SNMPv3, Telnet, RMON1, FTP |
SFP+ module slots quantity | 4 |
console port | RJ-45/Micro-USB |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Latency (10 Gbps) | 1.6 µs |
Throughput | 95.2 Mpps |
MAC Address Table | 32768 entries |
Packet buffer memory | 12.38 MB |
Latency (1 Gbps) | 3.8 µs |
Switching capacity | 128 Gbit/s |
Power Over Ethernet (PoE) | No |
Multicast support | Yes |
