Product Description | HPE Aruba Instant On 1930 24G 4SFP/SFP+ Switch - switch - 28 ports - Managed - rack-mountable |
Device type | Switch - 28 ports - L3 - Managed |
Enclosure Type | Rack-mountable 1U |
Subtype | Gigabit Ethernet |
Ports | 24 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ |
Performance | Switching capacity: 128 Gbps
Throughput: 95.23 Mpps
Latency (1 Gbps): 2.4 µs
Latency (10 Gbps): 1.3 µs |
Capacity | Link aggregation ports: 8
IPv4 routes (static): 32
VLANs supported: 256
Access Control Entries (ACEs) per ACL: 480
Packet buffer size: 1.5 MB |
MAC Address Table Size | 16000 entries |
Jumbo Frame Support | 9216 bytes |
Routing Protocol | Static IP routing |
Remote Management Protocol | SNMP 1, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, RADIUS |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
Power | AC 120/230 V (50/60 Hz) |
Dimensions (WxDxH) | 44.25 cm x 22.15 cm x 4.39 cm |
Weight | 2.41 kg |
Localisation | English / Europe |
Manufacturer Warranty | Limited lifetime warranty |
