Product colour | White |
Form factor | 1U |
Stackable | Yes |
Rack mounting | Yes |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power supply included | Yes |
Access Control List (ACL) | Yes |
Authentication | Port-based authentication |
DHCP features | DHCP snooping |
IGMP snooping | Yes |
Authentication type | RADIUS |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 15 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 15 - 95% |
Web-based management | Yes |
Switch layer | L2+ |
Switch type | Managed |
Quality of Service (QoS) support | Yes |
Cloud-managed | Yes |
Height | 44 mm |
Depth | 443 mm |
Weight | 3.9 kg |
Width | 350 mm |
Auto-sensing | Yes |
10G support | Yes |
Full duplex | Yes |
Flow control support | Yes |
Auto MDI/MDI-X | Yes |
Spanning tree protocol | Yes |
Networking standards | IEEE 802.1x |
Port mirroring | Yes |
Link aggregation | Yes |
VLAN support | Yes |
Processor model | ARM Cortex-A9 |
Physical stacking (units) | 4 |
Built-in processor | Yes |
Processor frequency | 800 MHz |
IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL) |
IPv4 FIB entries | 32 |
IPv6 FIB entries | 32 |
10G Ethernet (copper) ports quantity | 2 |
SFP+ module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Harmonized System (HS) code | 85176990 |
Latency (10-100 Mbps) | 4.4 µs |
Latency (10 Gbps) | 1.1 µs |
Jumbo Frames support | Yes |
Switching capacity | 128 Gbit/s |
Throughput | 95 Mpps |
Latency (1 Gbps) | 2.2 µs |
MAC Address Table | 16000 entries |
Power Over Ethernet (PoE) | No |
Multicast support | Yes |
