Product Description | HPE Aruba Networking CX 6200F 24G 4SFP+ Switch - switch - Max. Stacking Distance 10 kms - 24 ports - Managed - rack-mountable |
Device type | Switch - 24 ports - L3 - Managed - stackable |
Enclosure Type | Front and side to back rack-mountable 1U |
Subtype | Gigabit Ethernet |
Ports | 24 x 10/100/1000 + 4 x 100/1000/10G SFP+ |
Performance | Switching capacity: 128 Gbps
Throughput: 95.2 Mpps
Latency (1 Gbps): 2.28 µs
Latency (10 Gbps): 1.46 µs
Stacking bandwidth: 40 Gbps |
Capacity | Packet buffer size: 8 MB
IPv4 ACL entries (ingress): 5120
IPv6 ACL entries (ingress): 1280
MAC ACL entries (ingress): 5120
IPv4 ACL entries (egress): 2048
IPv6 ACL entries (egress): 512
MAC ACL entries (egress): 2048
IPv4 host table capacity: 8192
IPv6 host table capacity: 8192
IPv4 routes (Unicast): 2048
IPv6 routes (Unicast): 1024
IGMP groups: 1024
MLD groups: 1024 |
MAC Address Table Size | 32768 entries |
Jumbo Frame Support | 9220 bytes |
Routing Protocol | IGMP, IGMPv2, IGMPv3, RIP-2, OSPFv2, OSPFv3, MLD, MLDv2 |
Remote Management Protocol | CLI, MIB, RMON |
Compliant Standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w |
Power | AC 100-120/200-240 V (50/60 Hz) |
Dimensions (WxDxH) | 44.25 cm x 28.45 cm x 4.37 cm |
Weight | 3.77 kg |
System requirements | AOS-CX |
Localisation | English / Europe |
Manufacturer Warranty | Limited lifetime warranty |
