management functions | |
Switch-Typ | Managed |
switch level | L2+ |
Eigenschaft | Schnellstartübersicht |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 24 |
Quantity of SFP module slots | 2 |
Quantity of module slots SFP+ | 2 |
power plug | AC-Eingangsbuchse |
network | |
mesh standard | IEEE 802.1D, IEEE 802.1s, IEEE 802.1w |
Number of VLANs | 4096 |
data transmission | |
Routing/Switching Capacity | 98 Gbit/s |
Transferrate | 73 Mpps |
MAC-Adressentabelle | 16000 Eintragungen |
safety | |
DHCP functions | DHCP client, DHCP snooping |
Supported security algorithms | HTTPS, SSH |
multicast capabilities | |
Design | |
form factor | 1U |
Product color | Grau |
energy | |
energy source | AC |
Number of power supply units | 1 |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 24 |
Overall Power over Ethernet (PoE) | 400 W |
operating conditions | |
operating temperatur | -5 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 5 - 95% |
weight and dimensions | |
broad | 442 mm |
depth | 220 mm |
height | 43,6 mm |
scope of delivery | |
