management functions | |
Switch-Typ | Managed |
switch level | L3 |
Eigenschaft | Betriebsanleitung |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of SFP module slots | 8 |
Quantity of module slots SFP+ | 16 |
Anzahl QSFP28-Ports | 2 |
network | |
mesh standard | IEEE 802.1D, IEEE 802.1ag, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x |
Number of VLANs | 4000 |
data transmission | |
Routing/Switching Capacity | 1168 Gbit/s |
Transferrate | 867 Mpps |
MAC-Adressentabelle | 64000 Eintragungen |
safety | |
Supported security algorithms | SNMP, SNMPv2, SNMPv3 |
authentication | MAC-basierte Authentifizierung, Port-basierte Authentifizierung |
authentication type | HWTACACS, Network Access Control (NAC), RADIUS |
multicast capabilities | |
logs | |
management logs | SNMPv1/v2/v3 |
Supported network protocols | RIP, OSPF, IS-IS, BGP,RIPng, OSPFv3, IS-ISv6, BGP4+ |
Design | |
form factor | 1U |
Product color | Grau |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
DC input voltage | 48 - 60 V |
Power consumption (standard operation) | 122 W |
Power consumption (max.) | 127 W |
operating conditions | |
operating temperatur | -5 - 45 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 5 - 95% |
humidity during storage | 5 - 95% |
weight and dimensions | |
broad | 442 mm |
depth | 420 mm |
height | 43,6 mm |
Weight | 6,31 kg |
scope of delivery | |
