Certification | FCC Class B, VCCI Class A, CE, RoHS |
Form factor | 1U |
Product colour | Black |
Rack mounting | Yes |
Housing material | Metal |
LED indicators | Yes |
Power consumption (max) | 260 W |
Power protection features | Overload |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -10 - 70 °C |
Switch layer | L2 |
Switch type | Unmanaged |
Height | 44 mm |
Width | 442 mm |
Weight | 3.8 kg |
Depth | 208 mm |
Copper ethernet cabling technology | 1000BASE-T |
Full duplex | Yes |
Networking standards | IEEE 802.3 |
Cable types supported | Cat3 |
Auto MDI/MDI-X | Yes |
10G support | No |
Flow control support | Yes |
Buffer Size | 256 KB |
CABLES INCLUDED | AC |
Rack mount kit | Yes |
Manual | Yes |
Gigabit Ethernet (copper) ports quantity | 16 |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Harmonized System (HS) code | 85176990 |
Store-and-forward | Yes |
Switching capacity | 32 Gbit/s |
Forwarding rate | 1.488 Mpps |
MAC Address Table | 8192 entries |
Power Over Ethernet (PoE) | Yes |
