Certification | FCC A, CE, RoHS |
Product colour | Black |
LED indicators | Speed |
Number of fans | 2 fan(s) |
Rack mounting | Yes |
Housing material | Metal |
Stackable | No |
Power protection features | Short circuit |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Power consumption (max) | 420 W |
Storage temperature (T-T) | -10 - 70 °C |
Operating temperature (T-T) | 0 - 45 °C |
Operating relative humidity (H-H) | 10 - 90% |
Switch type | Unmanaged |
Height | 44 mm |
Width | 441.1 mm |
Depth | 204.3 mm |
Weight | 4 kg |
Flow control support | Yes |
Auto MDI/MDI-X | Yes |
10G support | No |
Networking standards | IEEE 802.3u |
Full duplex | Yes |
Copper ethernet cabling technology | 1000BASE-T |
Auto-sensing | Yes |
Cable types supported | Cat5 |
Noise level | 21.3 dB |
Mean time between failures (MTBF) | 144000 h |
Manual | Yes |
CABLES INCLUDED | AC |
Rack mount kit | Yes |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
SFP module slots quantity | 2 |
Harmonized System (HS) code | 85176990 |
Packet buffer memory | 0.5 MB |
MAC Address Table | 8192 entries |
Switching capacity | 36 Gbit/s |
Store-and-forward | Yes |
Packet forwarding rate (100 Mbps) | 148800 pps |
Packet forwarding rate (1 Gbps) | 1488000 pps |
Packet forwarding rate (10 Mbps) | 14880 pps |
Total Power over Ethernet (PoE) budget | 370 W |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) power per port | 30 W |
Power over Ethernet plus (PoE+) ports quantity | 16 |
