LED indicators | PoE |
Product colour | Black |
Form factor | 1U |
Number of fans | 2 fan(s) |
Housing material | Metal |
Rack mounting | Yes |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Power consumption (max) | 410 W |
ICMP attack prevention | Yes |
Security algorithms | SSH-2 |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -20 - 90 °C |
Operating relative humidity (H-H) | 10 - 90% |
Switch type | Managed |
Switch layer | L2+ |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Weight | 2.5 kg |
Width | 440 mm |
Depth | 208 mm |
Height | 44 mm |
Virtual LAN features | Port-based VLAN |
Broadcast storm control | Yes |
Auto-negotiation | Yes |
Spanning tree protocol | Yes |
Link aggregation | Yes |
Port mirroring | Yes |
Flow control support | Yes |
Rate limiting | Yes |
Cable types supported | Cat3 |
Auto-sensing | Yes |
Networking standards | IEEE 802.3af |
Full duplex | Yes |
Copper ethernet cabling technology | 100BASE-TX |
VLAN support | Yes |
Auto MDI/MDI-X | Yes |
Telnet | Yes |
Buffer Size | 512 KB |
Noise level | 45 dB |
Rack mount kit | Yes |
CABLES INCLUDED | AC |
Quick start guide | Yes |
Manual | Yes |
IPv4 & IPv6 features | Dual stack IPv4/IPv6 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
SFP module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Harmonized System (HS) code | 85176990 |
Packet forwarding rate (1 Gbps) | 1488000 pps |
Packet forwarding rate (10 Mbps) | 14880 pps |
MAC Address Table | 8000 entries |
Jumbo frames | 9000 |
Store-and-forward | Yes |
Forwarding rate | 1.488 Mpps |
Packet forwarding rate (100 Mbps) | 148800 pps |
Jumbo Frames support | Yes |
Switching capacity | 36 Gbit/s |
Power over Ethernet plus (PoE+) ports quantity | 16 |
Total Power over Ethernet (PoE) budget | 374 W |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) power per port | 30 W |
