Certification | FCC Class A, CE |
Housing material | Metal |
Rack mounting | Yes |
LED indicators | Yes |
Form factor | 1U |
Product colour | Black |
Power source | AC |
AC input voltage | 100 - 240 V |
Power consumption (max) | 20 W |
AC input frequency | 50 - 60 Hz |
Storage temperature (T-T) | -10 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Switch type | Unmanaged |
Switch layer | L2 |
Height | 44 mm |
Depth | 208 mm |
Width | 440 mm |
Weight | 3 kg |
Copper ethernet cabling technology | 10BASE-T |
MAC address auto-learning supported | Yes |
Full duplex | Yes |
Cable types supported | Cat4 |
MAC address auto-aging supported | Yes |
Auto-sensing | Yes |
10G support | No |
Flow control support | Yes |
Auto-negotiation | Yes |
Networking standards | IEEE 802.3az |
Auto MDI/MDI-X | Yes |
Buffer Size | 512 KB |
Mounting brackets included | Yes |
Rack mount kit | Yes |
CABLES INCLUDED | AC |
Manual | Yes |
Basic switching RJ-45 Ethernet ports quantity | 24 |
SFP module slots quantity | 2 |
Gigabit Ethernet (copper) ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Harmonized System (HS) code | 85176990 |
MAC Address Table | 8192 entries |
Switching capacity | 52 Gbit/s |
Forwarding rate | 1.488 Mpps |
Jumbo frames | 9000 |
Store-and-forward | Yes |
Jumbo Frames support | Yes |
Power Over Ethernet (PoE) | No |
