Certification | FCC Class A, CE |
Housing material | Metal |
Product colour | Black |
Form factor | 1U |
Rack mounting | Yes |
LED indicators | Yes |
AC input voltage | 100 - 240 V |
Power consumption (max) | 20 W |
Power source | AC |
AC input frequency | 50 - 60 Hz |
IGMP snooping | Yes |
Access Control List (ACL) | Yes |
Authentication | Port-based authentication |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Web-based management | Yes |
Switch type | Managed |
System event log | Yes |
Quality of Service (QoS) support | Yes |
Weight | 2.2 kg |
Width | 440 mm |
Depth | 205 mm |
Height | 44 mm |
Networking standards | IEEE 802.3 |
Link aggregation | Yes |
Cable types supported | Cat5 |
Rate limiting | Yes |
Port mirroring | Yes |
Full duplex | Yes |
Spanning tree protocol | Yes |
Auto-negotiation | Yes |
10G support | No |
Flow control support | Yes |
Broadcast storm control | Yes |
VLAN support | Yes |
Buffer Size | 512 KB |
Rack mount kit | Yes |
Mounting brackets included | Yes |
Manual | Yes |
CABLES INCLUDED | AC |
SFP module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Harmonized System (HS) code | 85176990 |
Switching capacity | 52 Gbit/s |
Jumbo Frames support | Yes |
Forwarding rate | 1.488 Mpps |
Jumbo frames | 9216 |
MAC Address Table | 8000 entries |
Store-and-forward | Yes |
Multicast support | Yes |
Number of multicast groups filtered | 8 |
