Certification | FCC B, CE, IEC61000-4-2, IEC61000-4-4, IEC61000-4-5 |
Housing material | Metal |
LED indicators | Power |
Product colour | Black |
Power supply included | Yes |
Power consumption (max) | 90 W |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -20 - 70 °C |
Height | 24 mm |
Depth | 110 mm |
Width | 160 mm |
Weight | 950 g |
Full duplex | Yes |
Copper ethernet cabling technology | 1000BASE-T |
Auto-negotiation | Yes |
10G support | No |
Flow control support | Yes |
Auto MDI/MDI-X | Yes |
Networking standards | IEEE 802.3af |
Harmonized System (HS) code | 85176990 |
Manual | Yes |
Quick start guide | Yes |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Power connector | DC-in jack |
Combo SFP ports quantity | 1 |
Packet forwarding rate (10 Mbps) | 14880 pps |
MAC Address Table | 2000 entries |
Packet forwarding rate (1 Gbps) | 1488000 pps |
Jumbo Frames support | Yes |
Store-and-forward | Yes |
Jumbo frames | 9000 |
Packet forwarding rate (100 Mbps) | 148800 pps |
Switching capacity | 10 Gbit/s |
Power over Ethernet (PoE) power per port | 30 W |
Total Power over Ethernet (PoE) budget | 80 W |
Power over Ethernet plus (PoE+) ports quantity | 4 |
Power Over Ethernet (PoE) | Yes |
