Certification | FCC Class A, CE, RoHS, UKCA, NDAA |
LED indicators | Power |
Wall mountable | Yes |
Housing material | Metal |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power source | AC |
Power consumption (max) | 72 W |
Power supply included | Yes |
Storage temperature (T-T) | 0 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Height | 32 mm |
Width | 168 mm |
Weight | 400 g |
Depth | 93 mm |
Networking standards | IEEE 802.3af |
10G support | No |
Full duplex | Yes |
Cable types supported | Cat5 |
Flow control support | Yes |
Copper ethernet cabling technology | 10BASE-T |
PACKAGE WEIGHT | 900 g |
CABLES INCLUDED | AC |
Manual | Yes |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Packet forwarding rate (10 Mbps) | 14880 pps |
Packet forwarding rate (1 Gbps) | 1488000 pps |
Switching capacity | 10 Gbit/s |
Packet forwarding rate (100 Mbps) | 148800 pps |
Store-and-forward | Yes |
MAC Address Table | 2048 entries |
Packet buffer memory | 1 MB |
Jumbo Frames support | Yes |
Power Over Ethernet (PoE) | Yes |
Total Power over Ethernet (PoE) budget | 65 W |
