Certification | FCC Class B, VCCI Class B, CE, RoHS, EN 60950-1 |
Product colour | Black |
Rack mounting | Yes |
LED indicators | Yes |
Housing material | Metal |
AC input frequency | 50 - 60 Hz |
Power source | AC |
AC input voltage | 100 - 240 V |
Power consumption (max) | 150 W |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -20 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Width | 280 mm |
Depth | 180 mm |
Height | 44 mm |
Weight | 2 kg |
Networking standards | IEEE 802.3x |
10G support | No |
Copper ethernet cabling technology | 100BASE-TX |
Full duplex | Yes |
Manual | Yes |
CABLES INCLUDED | AC |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Power LED | Yes |
Harmonized System (HS) code | 85176990 |
Store-and-forward | Yes |
Switching capacity | 16 Gbit/s |
MAC Address Table | 8000 entries |
Packet buffer memory | 256 MB |
Power Over Ethernet (PoE) | Yes |
