Certification | FCC, CE |
Housing material | Metal |
Form factor | 1U |
Rack mounting | Yes |
LED indicators | Yes |
Product colour | Black |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Operating temperature (T-T) | 5 - 55 °C |
Operating relative humidity (H-H) | 0 - 80% |
Switch type | Unmanaged |
Depth | 208 mm |
Width | 320 mm |
Height | 45 mm |
Networking standards | IEEE 802.3x |
Auto-negotiation | Yes |
Auto MDI/MDI-X | Yes |
Copper ethernet cabling technology | 1000BASE-T |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Combo SFP ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 16 |
Power over Ethernet (PoE) ports quantity | 16 |
Switching capacity | 7.2 Gbit/s |
MAC Address Table | 16000 entries |
Power over Ethernet plus (PoE+) ports quantity | 16 |
Total Power over Ethernet (PoE) budget | 150 W |
Power over Ethernet (PoE) power per port | 30 W |
Power Over Ethernet (PoE) | Yes |
