Product colour | Black |
Housing material | Metal |
Stackable | Yes |
Rack mounting | Yes |
Form factor | 1U |
Reset button | Yes |
AC input frequency | 50 - 60 Hz |
Power source | AC |
Power supply included | Yes |
AC input voltage | 100 - 240 V |
Power consumption (typical) | 26 W |
DHCP features | DHCP Option 67 |
Access Control List (ACL) | Yes |
Authentication type | IEEE 802.1x, RADIUS, TACACS+ |
IGMP proxy | Yes |
SSH/SSL support | Yes |
Authentication | Guest VLAN |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Configuring Location Settings (CLI) | Yes |
Web-based management | Yes |
Switch type | Managed |
Quality of Service (QoS) support | Yes |
Switch layer | L2 |
MIB support | Y |
Weight | 2.5 kg |
Depth | 170.3 mm |
Width | 442 mm |
Height | 44 mm |
VLAN support | Yes |
Flow control support | Yes |
Networking standards | IEEE 802.1ad |
Broadcast storm control | Yes |
Virtual LAN features | Private VLAN |
Cable length detection | Yes |
Spanning tree protocol | Yes |
Number of VLANs | 4096 |
10G support | No |
Link aggregation | Yes |
Port mirroring | Yes |
Firmware upgradeable | Yes |
Fanless | Yes |
Mounting brackets included | Yes |
Package depth | 500 mm |
Package height | 100 mm |
Package width | 310 mm |
PACKAGE WEIGHT | 3.2 kg |
Quick start guide | Yes |
CABLES INCLUDED | AC |
Compliance certificates | CE |
GARP VLAN Registration Protocol (GVRP) | Yes |
IP Source Guard (IPSG) | Yes |
Gigabit Ethernet (copper) ports quantity | 24 |
Power connector | AC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Combo SFP ports quantity | 2 |
console port | RJ-45 |
Harmonized System (HS) code | 85176990 |
Country of origin | Taiwan |
Customs product code (TARIC) | 85176200 |
Jumbo frames | 9000 |
Switching capacity | 52 Gbit/s |
Store-and-forward | Yes |
Jumbo Frames support | Yes |
Throughput | 38.69 Mpps |
MAC Address Table | 8000 entries |
Power Over Ethernet (PoE) | No |
Multicast support | Yes |
