Product colour | Black |
LED indicators | Yes |
Housing material | Metal |
Wall mountable | Yes |
Rack mounting | No |
Stackable | No |
AC input voltage | 220 V |
Power source | DC |
AC input frequency | 50 Hz |
Power consumption (typical) | 3.13 W |
Power supply included | Yes |
Power consumption (max) | 75.15 W |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Depth | 98 mm |
Width | 99.8 mm |
Height | 25 mm |
Networking standards | IEEE 802.3af |
Flow control support | Yes |
Auto MDI/MDI-X | Yes |
Auto-negotiation | Yes |
10G support | No |
Full duplex | Yes |
Half duplex | Yes |
Quick start guide | Yes |
CABLES INCLUDED | AC |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 5 |
MAC Address Table | 2000 entries |
Switching capacity | 10 Gbit/s |
Jumbo frames | 9 |
Jumbo Frames support | Yes |
Total Power over Ethernet (PoE) budget | 65 W |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 4 |
Warnings | The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations. |
Transmission distance (max) | 0.1 km |
