Wall mountable | Yes |
LED indicators | Yes |
Product colour | Black |
Rack mounting | No |
Stackable | No |
Housing material | Metal |
Power source | DC |
AC input voltage | 220 V |
AC input frequency | 50/60 Hz |
Input current | 0.6 A |
Power supply included | Yes |
Power consumption (max) | 4.22 W |
DC input voltage | 5 V |
Operating temperature (T-T) | 0 - 40 °C |
Heat dissipation | 14.348 BTU/h |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 95% |
Switch type | Unmanaged |
Depth | 99.1 mm |
Height | 25.2 mm |
Width | 158 mm |
MAC address auto-aging supported | Yes |
Auto MDI/MDI-X | Yes |
MAC address auto-learning supported | Yes |
Auto-negotiation | Yes |
Full duplex | Yes |
Networking standards | IEEE 802.3p |
10G support | No |
Flow control support | Yes |
Half duplex | Yes |
Fanless | Yes |
Quick start guide | Yes |
Manual | Yes |
CABLES INCLUDED | AC |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Jumbo frames | 15000 |
Store-and-forward | Yes |
Packet buffer memory | 0.5 MB |
MAC Address Table | 8000 entries |
Jumbo Frames support | Yes |
Switching capacity | 16 Gbit/s |
Power Over Ethernet (PoE) | No |
Warnings | The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations. |
Transmission distance (max) | 0.1 km |
