RAM | 128 MB |
Flash Memory | 32 MB |
Buffer memory | 512 KB |
Number of ports | 8 x 10Base-T/100Base-TX/1000Base-T (Ethernet/Fast Ethernet/Gigabit Ethernet) |
Switching method | Store and Forward |
Switching Layers | Layer 2 Layer 3 Layer 4 |
MAC Address Table Size | 8K |
Network/Transport Protocol | IPv4 TCP/IP UDP HTTP IPv6 TFTP DNS UPnP HTTPS QoS IGMP SNMP IGMPv2 MLDv1 RMON IGMPv3 MLDv2 SIP LLDP |
Status LED Indicators | Activity Status, Link, Speed |
Data Transmission | Full Duplex |
Networking Compliant Standards | IEEE 802.1D(Spanning Tree Protocol) IEEE 802.1p(QoS) IEEE 802.1Q(VLAN) IEEE 802.1X IEEE 802.3ad IEEE 802.1w IEEE 802.1ab IEEE 802.3az IEEE 802.1s |
Networking Features | DHCP Client Built-in Jumbo Frames Support DoS Attack Protection Radius/TACACS+ |
Device Location | External |
Mounting Capability | Desktop/Wallmount |
LAN | 8 (RJ-45) |
Power Consumption Operational | 5.5 W |
Power Consumption Stand By/Sleep | 1.9 W |
Depth (mm) | 101 mm |
Height (mm) | 27 mm |
Width (mm) | 158 mm |
Nominal Weight | 0.43 kg |
External Color | Gray |
Maximum Operating Ambient Temperature | 40 °C |
Maximum Operating Humidity | 95 % |
Minimum Operating Ambient Temperature | 0 °C |
Mean Time Between Failures | 2388657 hr |
Warranty Term (month) | 60 month(s) |
Warranty Validation Criteria | Serial Number |
Pack Length (mm) | 101 mm |
Pack Width (mm) | 158 mm |
Pack Height (mm) | 27 mm |
Box Weight Brutto (kg) | 0.7 kg |
Package Type | Box |
