management functions | |
Switch-Typ | Managed |
switch level | L2 |
Eigenschaft | LED-Anzeigen |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 12 |
Basic Switching RJ-45 Ethernet Ports-Typ | 10G Ethernet (100/1000/10000) |
Quantity of module slots SFP+ | 2 |
power plug | DC-Anschluss |
network | |
mesh standard | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Virtual LAN functions | Port-based VLAN |
Number of VLANs | 64 |
data transmission | |
Routing/Switching Capacity | 240 Gbit/s |
MAC-Adressentabelle | 32000 Eintragungen |
Jumbo-Frames | 9000 |
Data packet buffer memory | 3 MB |
safety | |
DHCP functions | DHCP client |
Design | |
form factor | 1U |
Product color | Blau, Grau |
number of fans | 2 Lüfter |
Services | |
Mean Time Between Failures (MTBF) | 1113477 h |
energy | |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
input current | 2 A |
operating conditions | |
operating temperatur | 0 - 50 °C |
Storage temperature range | -20 - 70 °C |
Operating relative humidity | 0 - 90% |
humidity during storage | 0 - 95% |
heat dissipation | 261,38 BTU/h |
weight and dimensions | |
broad | 328 mm |
depth | 204 mm |
height | 43 mm |
Weight | 2,51 kg |
sustainability | |
sustainability certificates | ENERGY STAR |
logistic data | |
Goods tariff number (HS) | 85176990 |
