| management functions | |
| Switch-Typ | Managed |
| switch level | L3 |
| Eigenschaft | Nachhaltigkeitskonformität |
| connections and interfaces | |
| Number of basic switching RJ-45 Ethernet ports | 12 |
| Basic Switching RJ-45 Ethernet Ports-Typ | 10G Ethernet (100/1000/10000) |
| Number of 10G Ethernet (copper) ports | 12 |
| Quantity of module slots SFP+ | 12 |
| power plug | AC-Eingangsbuchse |
| network | |
| IPv4-Routen | 512 |
| IPv6-Routen | 256 |
| Virtual LAN functions | MAC address-based VLAN, Private VLAN, Voice VLAN |
| Number of VLANs | 4093 |
| data transmission | |
| Routing/Switching Capacity | 480 Gbit/s |
| passage | 357,12 Mpps |
| MAC-Adressentabelle | 16000 Eintragungen |
| Latency (1Gbps) | 2,14 µs |
| Latency (10 Gbps) | 2,29 µs |
| Jumbo-Frames | 12000 |
| Data packet buffer memory | 32 MB |
| safety | |
| DHCP functions | DHCP Option 150, DHCP Option 66, DHCP Option 67, DHCP relay, DHCP server, DHCP snooping |
| Zugriffskontrollliste (ACL) Ausgang | 1023 |
| Zugriffskontrollliste (ACL) Eingang | 511 |
| authentication | Gast VLAN, MAC-basierte Authentifizierung |
| authentication type | RADIUS, TACACS+ |
| Queue Scheduling Algorithms | Strict Priority Queue (SPQ), Weighted random early detection (WRED) |
| multicast capabilities | |
| logs | |
| management logs | SNMP V1, V2, V3 |
| Router protocol | OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2 |
| Design | |
| form factor | 1U |
| Product color | Schwarz |
| Airflow direction | Luftstrom von vorne nach hinten |
| Services | |
| processor | ARM Cortex-A57 |
| processor clock speed | 1800 MHz |
| storage type | DDR4-SDRAM |
| storage capacity | 2048 MB |
| Flash memory | 512 MB |
| energy | |
| energy source | AC |
| Power consumption (standard operation) | 95,8 W |
| Other functions | |
| power supply | 240 W |
| operating conditions | |
| operating temperatur | 0 - 50 °C |
| Storage temperature range | -20 - 70 °C |
| Operating relative humidity | 0 - 90% |
| humidity during storage | 0 - 95% |
| operating height | 0 - 3000 m |
| storage height | 0 - 3000 m |
| weight and dimensions | |
| broad | 220 mm |
| depth | 400 mm |
| height | 43,2 mm |
| Weight | 4,3 kg |
| scope of delivery | |
| Supplied cables | AC, USB Typ-C |
| Plug types included | EU, UK, NA |
| sustainability | |
| certificates | |
| Konformitätsbescheinigungen | BSMI, CCC, CE, Eidgenössische Kommunikationskommission (FCC), Niederspannungsrichtlinie (LVD) |
