management functions | |
Switch-Typ | Managed |
switch level | L2/L3/L4 |
Eigenschaft | Power over Ethernet (PoE) |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of installed SFP modules | 4 |
Anzahl der USB Typ-A-Anschlüsse | 1 |
network | |
mesh standard | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3x |
IPv4-Routen | 32 |
IPv6-Routen | 32 |
Number of VLANs | 256 |
data transmission | |
Routing/Switching Capacity | 56 Gbit/s |
MAC-Adressentabelle | 16000 Eintragungen |
Latency (10-100Mbps) | 8,871 µs |
Latency (1Gbps) | 4,701 µs |
Data packet buffer memory | 1,5 MB |
safety | |
DHCP functions | DHCP snooping, DHCPv6 client |
Zugriffskontrollliste (ACL) IPv4-Einträge | 100 |
multicast capabilities | |
Number of filtered multicast groups | 512 |
Design | |
Product color | Grau |
number of fans | 2 Lüfter |
Services | |
processor manufacturer | ARM |
processor | ARM Cortex-A55 |
processor clock speed | 800 MHz |
storage capacity | 512 MB |
Flash memory | 64 MB |
noise level | 33,3 dB |
Mean Time Between Failures (MTBF) | 1252990 h |
energy | |
energy source | AC |
Power consumption (standard operation) | 26 W |
Power consumption (max.) | 427 W |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 24 |
Power over Ethernet (PoE) performance per port | 380 W |
operating conditions | |
operating temperatur | 0 - 50 °C |
Storage temperature range | -20 - 70 °C |
Operating relative humidity | 0 - 90% |
humidity during storage | 0 - 95% |
weight and dimensions | |
broad | 440 mm |
depth | 257 mm |
height | 432 mm |
Weight | 4,11 kg |
certificates | |
certification | CE, FCC Class A, RCM, ICES Class A, VCCI, KC, BSMI, UKCA |
