management functions | |
Switch-Typ | Managed |
switch level | L2/L3/L4 |
Eigenschaft | Power over Ethernet (PoE) |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | 10G Ethernet (100/1000/10000) |
Quantity of module slots SFP+ | 2 |
console port | RJ-45 |
Number of USB 2.0 ports | 1 |
network | |
mesh standard | IEEE 802.1x, IEEE 802.3ad, IEEE 802.3az |
Copper Ethernet cabling technology | 10GBASE-T |
Virtual LAN functions | Private VLAN |
Number of VLANs | 4096 |
data transmission | |
Routing/Switching Capacity | 128 Gbit/s |
Transferrate | 357 Mpps |
MAC-Adressentabelle | 16000 Eintragungen |
Latency (10 Gbps) | 2,74 µs |
Number of static routes | 64 |
Data packet buffer memory | 16 MB |
safety | |
DHCP functions | DHCP server |
Supported security algorithms | HTTPS, SNMP, SSH |
multicast capabilities | |
Number of filtered multicast groups | 4000 |
Design | |
form factor | 1U |
Product color | Schwarz |
number of fans | 1 Lüfter |
Services | |
processor clock speed | 800 MHz |
storage capacity | 1024 MB |
Flash memory | 256 MB |
noise level | 39,8 dB |
energy | |
Number of power supply units | 1 |
AC input voltage | 110 - 240 V |
Power consumption (standard operation) | 577 W |
Power consumption (max.) | 833,2 W |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 24 |
Overall Power over Ethernet (PoE) | 480 W |
operating conditions | |
heat dissipation | 196988 BTU/h |
weight and dimensions | |
Weight | 5,09 kg |
logistic data | |
Goods tariff number (HS) | 85176990 |
