Certification | 47 CFR FCC, ICES-003:2016 Issue 6, ANSI C63.4:2014, EN 55032:2012+AC2013, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 32:2015, VCCI V-3/2015.04, V-4/2012.4, CNS 13438 |
LED indicators | Yes |
Product colour | Silver |
Rack mounting | Yes |
Safety | CE: CB 60950-1, LVD 60950-1, AUS/NZ: AS/NZS 60950-1, USA: UL 60950-1, SNE VA, BSMI |
AC input voltage | 100 - 240 V |
Input current | 1.5 A |
AC input frequency | 50 - 60 Hz |
Power source | AC |
Power consumption (max) | 22.5 W |
Power consumption (typical) | 12.25 W |
Operating altitude | 0 - 3000 m |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -20 - 70 °C |
Operating temperature (T-T) | 0 - 50 °C |
Heat dissipation | 85.3 BTU/h |
Quality of Service (QoS) support | Yes |
Switch type | Unmanaged |
Weight | 1.38 kg |
Depth | 169 mm |
Width | 328 mm |
Height | 43.2 mm |
Networking standards | IEEE 802.3z |
10G support | Yes |
Full duplex | Yes |
Flow control support | Yes |
Mean time between failures (MTBF) | 1093237 h |
Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 4 |
SFP+ module slots quantity | 1 |
Harmonized System (HS) code | 85176990 |
Packet buffer memory | 128 MB |
Jumbo Frames support | Yes |
Switching capacity | 100 Gbit/s |
MAC Address Table | 2000 entries |
Jumbo frames | 9000 |
Power Over Ethernet (PoE) | No |
