Rack mounting | Yes |
Form factor | 1U |
Product colour | Blue |
LED indicators | Yes |
Number of fans | 2 fan(s) |
AC input voltage | 100 - 240 V |
Input current | 2 A |
AC input frequency | 50 - 60 Hz |
DHCP features | DHCP client |
MAC address filtering | Yes |
IGMP snooping | Yes |
Operating relative humidity (H-H) | 0 - 90% |
Storage relative humidity (H-H) | 0 - 95% |
Heat dissipation | 261.38 BTU/h |
Storage temperature (T-T) | -20 - 70 °C |
Operating temperature (T-T) | 0 - 50 °C |
Switch layer | L2 |
Switch type | Managed |
Quality of Service (QoS) support | Yes |
Width | 328 mm |
Depth | 204 mm |
Height | 43 mm |
Weight | 2.51 kg |
Networking standards | IEEE 802.1Q |
Number of VLANs | 64 |
Virtual LAN features | Port-based VLAN |
VLAN support | Yes |
10G support | Yes |
Broadcast storm control | Yes |
Mean time between failures (MTBF) | 1113477 h |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 12 |
SFP+ module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
Harmonized System (HS) code | 85176990 |
Packet buffer memory | 3 MB |
Switching capacity | 240 Gbit/s |
Jumbo frames | 9000 |
Store-and-forward | Yes |
Jumbo Frames support | Yes |
MAC Address Table | 32000 entries |
Power Over Ethernet (PoE) | No |
Sustainability certificates | ENERGY STAR |
