Certification | FCC Part 15 Class A, CE
IEC 60068-2-32 (free fall)
IEC 60068-2-27 (shock)
IEC 60068-2-6 (vibration) |
Housing material | Metal |
LED indicators | Yes |
Wall mountable | Yes |
International Protection (IP) code | IP30 |
Product colour | Blue |
DIN rail mounting | Yes |
Redundant power supply (RPS) support | Yes |
Power consumption (typical) | 3.6 W |
DC input voltage | 24 V |
Storage relative humidity (H-H) | 5 - 90% |
Operating temperature (T-T) | -40 - 75 °C |
Heat dissipation | 12.35 BTU/h |
Storage temperature (T-T) | -40 - 75 °C |
Operating relative humidity (H-H) | 5 - 90% |
Switch type | Unmanaged |
Weight | 252 g |
Width | 30 mm |
Height | 104 mm |
Depth | 70 mm |
Networking standards | IEEE 802.3az |
MAC address auto-aging supported | Yes |
Flow control support | Yes |
Full duplex | Yes |
Cable types supported | Cat3 |
Auto MDI/MDI-X | Yes |
10G support | No |
Auto-negotiation | Yes |
MAC address auto-learning supported | Yes |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (copper) ports quantity | 5 |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Harmonized System (HS) code | 85176990 |
Jumbo frames | 9000 |
Switching capacity | 10 Gbit/s |
Throughput | 7.4 Mpps |
Packet buffer memory | 1 MB |
Store-and-forward | Yes |
MAC Address Table | 4000 entries |
Jumbo Frames support | Yes |
Power Over Ethernet (PoE) | No |
