Certification | FCC Part 15 Class A, CE |
Rack mounting | No |
Stackable | No |
Wall mountable | Yes |
DIN rail mounting | Yes |
Housing material | Metal |
LED indicators | Yes |
Product colour | Blue |
International Protection (IP) code | IP30 |
DC input voltage | 12 - 48 V |
Power supply included | No |
Power consumption (typical) | 7.5 W |
Operating relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | -40 - 75 °C |
Storage temperature (T-T) | -40 - 75 °C |
Storage relative humidity (H-H) | 5 - 95% |
Switch type | Unmanaged |
Width | 32 mm |
Depth | 87 mm |
Height | 135 mm |
Weight | 425 g |
Auto-negotiation | Yes |
Flow control support | Yes |
Copper ethernet cabling technology | 10BASE-T |
Full duplex | Yes |
Cable types supported | Cat5 |
10G support | No |
Networking standards | IEEE 802.3x |
Auto MDI/MDI-X | Yes |
Half duplex | Yes |
Basic switching RJ-45 Ethernet ports quantity | 4 |
SFP module slots quantity | 2 |
Fiber optic connector | SFP |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Harmonized System (HS) code | 85176990 |
MAC Address Table | 4000 entries |
Jumbo Frames support | Yes |
Store-and-forward | Yes |
Jumbo frames | 9216 |
Switching capacity | 18 Gbit/s |
Throughput | 13.39 Mpps |
Power Over Ethernet (PoE) | No |
Transmission distance (max) | 60 km |
Fiber type | Multi-mode |
Fiber ethernet cabling technology | 100BASE-FX |
