DIN rail mounting | Yes |
Rack mounting | Yes |
Reset button | Yes |
Form factor | 1U |
Product colour | Blue |
LED indicators | Yes |
Housing material | Metal |
International Protection (IP) code | IP30 |
Wall mountable | Yes |
Power consumption (max) | 10 W |
Power consumption (typical) | 4.5 W |
Authentication | Port-based authentication |
SSH/SSL support | Yes |
Access Control List (ACL) | Yes |
BPDU filtering/protection | Yes |
IGMP snooping | Yes |
Loop protection | Yes |
Security algorithms | SSH |
MAC address filtering | Yes |
Heat dissipation | 15 BTU/h |
Operating relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | -40 - 75 °C |
Storage temperature (T-T) | -40 - 75 °C |
Storage relative humidity (H-H) | 5 - 95% |
Switch type | Managed |
Switch layer | L2/L4 |
System event log | Yes |
ARP inspection | Yes |
Traffic classification | Yes |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Weight | 472 g |
Height | 135 mm |
Width | 32 mm |
Depth | 87 mm |
Virtual LAN features | Private VLAN |
Spanning tree protocol | Yes |
Link aggregation | Yes |
Flow control support | Yes |
Broadcast storm control | Yes |
Half duplex | Yes |
Port mirroring | Yes |
Rate limiting | Yes |
Copper ethernet cabling technology | 100BASE-TX |
VLAN support | Yes |
Networking standards | IEEE 802.3 |
Full duplex | Yes |
Auto MDI/MDI-X | Yes |
10G support | No |
Number of VLANs | 4094 |
Firmware upgradeable | Yes |
Management protocols | Telnet/SNMP |
Supported network protocols | IPv4 / IPv6 |
Gigabit Ethernet (copper) ports quantity | 8 |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Terminal block port | Yes |
Harmonized System (HS) code | 85176990 |
Jumbo frames | 10000 |
Throughput | 11.9 Mpps |
Number of queues | 8 |
Store-and-forward | Yes |
Switching capacity | 16 Gbit/s |
MAC Address Table | 8000 entries |
Jumbo Frames support | Yes |
Power Over Ethernet (PoE) | No |
Multicast support | Yes |
Number of multicast groups filtered | 256 |
