LED indicators | Yes |
Product colour | Blue |
International Protection (IP) code | IP30 |
Rack mounting | No |
Wall mountable | Yes |
Housing material | Metal |
Power consumption (max) | 16 W |
Redundant power supply (RPS) support | Yes |
Operating temperature (T-T) | -40 - 75 °C |
Storage temperature (T-T) | -40 - 85 °C |
Operating relative humidity (H-H) | 5 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Heat dissipation | 54 BTU/h |
Switch layer | L2 |
Switch type | Unmanaged |
Weight | 442 g |
Width | 135 mm |
Depth | 97 mm |
Height | 32 mm |
Networking standards | IEEE 802.3u |
Copper ethernet cabling technology | 100BASE-TX |
MAC address auto-learning supported | Yes |
Full duplex | Yes |
MAC address auto-aging supported | Yes |
Flow control support | Yes |
10G support | No |
Auto MDI/MDI-X | Yes |
Basic switching RJ-45 Ethernet ports quantity | 4 |
Fiber optic connector | LC |
Fast Ethernet (copper) ports quantity | 4 |
SFP module slots quantity | 2 |
Fiber ports quantity | 2 |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Harmonized System (HS) code | 85176990 |
Switching capacity | 1.2 Gbit/s |
Store-and-forward | Yes |
Throughput | 0.89 Mpps |
MAC Address Table | 2048 entries |
Power Over Ethernet (PoE) | No |
Fiber ethernet cabling technology | 100BASE-FX |
